CLG HARDWARE Heavy Duty Commercial Door Closer DC8016 - Slim Line - Surface Mounted, Grade 1- ADA & UL 3 Hour Fire Rated, Adjustable Size 1-6 for Entrances & Aluminum Storefronts - US10D Dark Bronze
4.0 (71 items)
Limited Time SaleUS$112.18 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211283526 | Release Date | 2026/04/04 | List Price | US$74.78 | Model Number | 211283526 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- PREMIUM COMMERCIAL-GRADE PERFORMANCE: Made with a powder-coated cast aluminum body, wrought steel arm, and heat-treated piston, this commercial door closer ensures durability, reliability, and corrosion resistance for doors in high-traffic areas (up to 2,000 openings per day); suitable for commercial entrances, school corridor doors, offices, and restrooms
- THREE MOUNTING OPTIONS: This non-handed auto door closer (works on left or right-handed doors) includes three mounting options to suit any door and frame type (pull side or push side), including regular arm mount, top jamb mount, or parallel arm mount; all required hardware, a drill hole template, and easy-to-follow instructions are included for hassle-free installation
- 5 ADJUSTMENT VALVES FOR COMPLETE CONTROL: This hydraulic door closer features 5 adjustment valves to control the closing speed, latching speed, backcheck, spring force, and a delayed closing timer; fine-tune for smooth, quiet, and secure closing
- CERTIFIED FOR SAFETY AND LONG-TERM USE: UL 3-Hour Fire Rated, ADA Compliant, and ANSI/BHMA A156.4 Certified (tested to exceed 2 million cycles), ensuring safety and reliability; the DC8016 door closer is trusted by contractors, property managers, and builders
- USA SUPPLIED & SUPPORTED: Our commercial door closers are supplied by a USA-based company, providing reliable year-round support
- SPECIFICATIONS: This door closer weighs 7.4 lbs (3.36 kg) and is for doors weighing up to 330 lbs (150 kg) and 60” (1500 mm) wide; it’s dimensions are 2 7/8" (73 mm) high, 13 1/16" (332 mm) wide and 2 1/8" (73 mm) deep; its screw/bolt pattern is 12" wide (center to center) and 1 7/8" high (center to center); the spring force is adjustable from Setting # 1 (2 pounds of closing force) through to Setting # 6 (14 pounds of closing force)
| UPC | 195893243860 |
|---|---|
| Size | Heavy Duty |
| Style | Grade 1 |
| Item Weight | 6 pounds |
| Part Number | CLG-CLG8016-BC-DA-DURO |
| Manufacturer | CLG HARDWARE |
| Special Features | Machine and Wood Screws |
| Installation Type | Screw-In |
| Item model number | DC8016 |
| Specification Met | ADA, ANSI, UL |
| Batteries Included | No |
| Batteries Required | No |
| Package Dimensions | 13.98 x 5.59 x 2.91 inches |
| Included Components | Brackets and Soffit Plate to allow Regular/Top Jamb/Parallel Arm Installations |
| Item Package Quantity | 1 |
| Recommended Uses For Product | heavy traffic entrances and doorways, aluminum storefronts, factories, schools, offices, restaurants, and other public spaces |
