EMX USVD-4X Ultrasonic Vehicle Detector 12-24VAC VDC TPA Technology Form C Relay

The EMX USVD-4X is an ultrasonic vehicle detector designed for drive thru vehicle presence detection across common operations such as fast food, banking, pharmacies, car washes, and parking. Instead of installing an in ground inductive loop, the USVD-4X is mounted above ground on a post or an order box and aimed at the location where a vehicle will pass to initiate a transaction. This approach can reduce installation cost and simplify deployment. The detector uses Triangular Planar Array TPA technology. Its detection head contains four ultrasonic transducers that connect to an internal microprocessor based control board, which scans the expected vehicle location and activates output upon detection. Power is 12-24VAC or VDC, and output is provided through a Form C set of relay contacts indicating vehicle presence for integration with your drive thru or access system.

• Ultrasonic vehicle detector for drive thru operations like fast food banking pharmacy car wash parking
• Uses Triangular Planar Array TPA technology to detect vehicle presence without pavement loops
• Above ground mount on a post or order box, aim at the vehicle location, no setup adjustments required
• Detection head uses 4 ultrasonic transducers connected to an internal microprocessor control board
• 12-24VAC VDC power with Form C relay contacts to signal vehicle presence to your system
