H07V-K 16 mm² Brown 10 Metre Flexible Wiring Cable Single Core Stranded PVC 16 mm2

Fine-stranded wire cable H07V-K for use in dry rooms, in equipment, switching and distribution systems, in pipes on or under plaster as well as for protected installation in luminaires. Approved for internal wiring of devices up to a mains voltage of 1000V AC and up to 750V DC to Earth. Conductor manufactured according to harmonised standard (H) for rated voltage 450/750 V (07) in PVC insulation (V) with flexible multi-strand copper core (K). It consists of a flexible copper multi-wire of class 5 (fine-stranded), according to the standard PN-EN 60228. The cable jacket is made of durable PVC material. Operating temperature from -40°C to +70°C. The rated voltage is 450/750V, and the outer diameter of the cable is 7.1mm. The maximum bending radius is four times the cable diameter (4xD), whereby careful bending up to twice the diameter (2xD) is possible at the cable end. Installation note: When wiring in lights where the connection area of the wires is not protected from UV radiation and heat (caused by the bulbs), a protective hose must be pushed over the exposed wires. Otherwise, depending on the duty cycle a decomposition of the insulation occurs. Not permitted for direct installation in plaster, laying on flatbeds, in tubs (except covered plastic tubs) and the like.

• Versatile applications: the fine-stranded wire cable is suitable for dry rooms, ideal for equipment, switching and distribution systems, pipes and protected luminaire installations.
• High-quality materials: flexible copper multi-wire (class 5) with durable PVC jacket, manufactured to PN-EN 60228 and harmonised standard H for the highest quality.
• The H07V-K is suitable for wiring control cabinets, machines, devices and lights.
• Approved for internal wiring of devices up to 1000V AC and 750V DC to earth approved.
• Important installation instructions: UV and heat protected installation required; not suitable for direct installation in plaster or open installations such as flatbeds and tubs.
