NEWTRY HA500 Automatic 500ml/min High Purity 99.999% H2 Hydrogen Generator Gas Machine (110V)

Product Description ⑴This instrument is mainly composed of electrolysis system, pressure control system and purification system. ⑵Electrolysis hydrogen uses advanced membrane separation technology, which controls the pressure by the infrared photoelectric device, so that the output of hydrogen can be adjusted automatically according to the requirement, and the pressure is maintained stable. ⑶It can replace high pressure hydrogen gas cylinder, and it is safe and convenient to use. Automatic control, easy to operate. ⑷The generator's internal pipeline has a device to prevent liquid return, which can effectively prevent liquid return. ⑸It can be used continuously or intermittently, with stable gas production and no decay in purity. ⑹There is an overvoltage protection device, which is safe and reliable. Technical Parameter Output flow: 0-500ml/min; Output pressure: 0~ 0.4Mpa The purity of hydrogen: >99.999% Pressure stability: <0.2% Secondary protection pressure:0.5MP Tank volume: 1.5L Water consumption: 25ml/h Water quality requirements: resistivity ≥1MΩ/cm Maximum power: 180W output interface: 3mm or 1/8in (M8 x 1 external thread) Working conditions: Ambient temperature 10~40℃, relative humidity <85%, no serious dust pollution The shape size: 420×200×330mm (L x W x H) Work pattern: continuous work Packing weight: 14kg Attention: we will send the product to you as soon as possible

• This instrument is mainly composed of electrolysis system, pressure control system and purification system.
• It can replace high pressure hydrogen gas cylinder, and it is safe and convenient to use. Automatic control, easy to operate.
• The generator's internal pipeline has a device to prevent liquid return, which can effectively prevent liquid return.
• It can be used continuously or intermittently, with stable gas production and no decay in purity.
• There is an overvoltage protection device, which is safe and reliable.
