PR18-8DP DC 6-36V PNP NO 3-Wires 8mm Inductive Proximity Sensor Approach Switch
4.7 (121 items)
Limited Time SaleUS$23.03 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221452861 | Release Date | 2026/05/03 | List Price | US$15.35 | Model Number | 221452861 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Proximity SensorsProduct Name Proximity Switch Model PR18-8DP Wire Type 3 Wire Theory Inductive Sensor Output Type PNP NO(Normal Open) Diameter of Head 18mm Detecting Distance 8mm±10% Hysteresis Max. 10% of Detecting Distance Standard Detecting Target Size: 25 x 25 x 1mm Material: Iron Setting Distance 0 to 5.6 Supply Voltage DC 6-36V Current Consumption 10mA Response Frequency 200Hz Residual Voltage Max. 1.5V Variation Due To Temp. Fluctuation Max.+10% of Detecting Distance at +20°C within Temperature Range of -25°C to +70°C Control Output 300mA Insulation Resistance Min. 50m (500VDC) Electric Strength 1500V AC 50/60Hz for 1 Minute Vibration 1mm Amplitude at Frequency of 10 to 55Hz in Each of X, Y, Z Directions for 2 Hours Shock 500m/S*(50G) X, Y, Z Directions for 3 Times Ambient Temperature -25°C to +70°C (Non-freezing Condition) Storage Temperature -30°C to +80°C (Non-freezing Condition) Ambient Humidity 35 to 95% RH Protection Circuit Reverse polarity protection, surge protection, overload & short circuit protection exception PRS 12 Size 5 x 3cm 2' x 1.2'' (L*Max. Dia) Cable Length 140cm / 55.1" Extenal Material ABS Resin Each bid for 1pc!
- Proximity Sensors
- PR18-8DP DC 6-36V PNP NO 3-Wires 8mm Inductive Proximity Sensor Approach Switch
| Color | One Color |
|---|---|
| Model | JDOUNFMO |
| Brand Name | JDOUNFMO |
| Unit Count | 1.0 Count |
| Item Weight | 50 Grams |
| Part Number | JDOUNFMO |
| Manufacturer | JDOUNFMO |
| Material Type | Copper |
| Number of Items | 1 |
