Upgrade 18 Amp 48 Volt Golf Carts Battery Charger for 2007-2024 Yamaha G29 Drive & Drive 2 Lead-Acid Battery Smart Trickle Charger with 3-Pin Leaf Plug IP67 Waterproof

Please verify that the connector matches the receptacle on your golf cart. Product Features: 1.Up to 93% work efficiency 2.Strong protection function 3.Working temperature scope of wide temperature range 4.100% full loading agingtest 5.Quake proof degree of automotive grade Protection Functions: 1.Short-circuit protection 2.Over-current protection 3.Over-voltage protection 4.Reverse Polarity Protection 5.Over-temperature protection Specification: Item Type: Golf Cart Battery Charger Shell Material: Aluminium Casting Weight:2.72 Kg( 6.0 lbs) Dimensions:11*3.34*5.03 inch AC Input Voltage: 85-265 VAC Nominal AC Input Frequency: 50 / 60 Hz Maximum DC Output Voltage: 58.8 V Nominal DC Output Voltage:48 V Max DC Output Current: 18A @ 110 VAC, 18A @ 220 VAC Charging Mode:CC, CV, Trickle Power factor: ＞93% Operating Temperature: -20℃~60℃（-4℉~149℉), Derated at＞ 40℃（104℉） Storage Temperature: -40℃~85℃（-40℉~185℉) Cooling: Active cooling with fan Humidity: 5%- 95% Waterproof Level: IP67 Compatible battery: 48V Lead-Acid EXPLANATION OF LED STATUS: Standby state( connect the ac power, not connect the battery): The green and red lights flash alternately Charging: Red light on, the power is less than 80% Charging: Yellow light on, the power is more than 80%, yellow light on Trickle mode: The green light flash Fully charged: Green light on Note: This charger with a Relay for Reverse Polarity Protection, it doesn't have output voltage and current when charger AC power on but disconnecting with the battery. It will have voltage and current output when it connects with battery.

• 🚀【Upgraded 18 Amp Golf Cart Battery Rapid Charger】This 48 volt golf cart charger features a 3-Pin Leaf Plug,ideal for 48 volt 2007-2024 Yamaha G29 Drive & Drive 2 golf carts models with six 8-volt lead-acid batteries, it provides faster charging for your golf cart batteries reduces waiting time.This charger is 80% lighter than the EZGO OEM model, It is easy to transport and store.
• 【Extended 16Ft Power Cables】Our 48 volt club cart golf cart charger designed with convenience of 16ft length heavy-duty cable (9.8ft power cable and 5.9ft output cable), lets you easily adjust the position while charging,allowing you to charge up your batteries anywhere. It features a carry handle on its top for easier carrying it around.
• 【Advanced Safety】The smart golf cart charger features protection from overcharge, short-circuit, temperature protection, reverse polarity and over-heating(when inside temperature over 75 degree Celsius,it stop charge for about 10 seconds and then recover automatically), which means that you can use it with confidence, keep your battery in good condition . With temperature sensor can sense ambient temperature and automatically adjust the charging voltage to to achieve the best charging effect and protect the health of the battery.
• 【Durable & Waterproof】This intelligent golf cart charger with a fully sealed design, offers an IP67 weather resistance rating, perfect for outdoor use.The fan of the charger is covered with a steel plate that protects the fan, which is an improvement over other models in the market.
• 【LED indicator shows the status of the charge】The golf cart charger designed with an three-color LED indicator that shows the status of the charge.Red/Green Flash:Waiting mode or no-Load; Red Flash: Low Charging(<80%); Yellow Flash: Normal Charging(>80%); Green Flash: Trickle Mode(≈ 100%); Green On: Fully Charged(100%). This golf cart charger is set with a maximum charging time (15 hours), when the charging time reaches 15 hours, the charger will automatically stop output to prevent overcharging.
